Manometers-Inbuilt Sensors

A range of high quality pressure measurement devices with integrated sensors

GMH3181-07H picture
GMH 3181-07H Fine Manometer ( -1.00 ... +70.00 mbar rel. *)

Features:

Measuring range: -1.00 ... +70.00 mbar
Overload: max. 1000 mbar
Accuracy (typ. values):
- ± 0,1% Full Scale (hysteresis and linearity)
- ± 0,4% Full Scale (temperature influence from 0-50 °C)

Additional pressure units: bar, kPa, MPa, PSI, mH2O
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset d.c. connector, serial interface. 2 metal connection pins, Ø 4 mm, piezo-resistive sensor.
Scope of supply: 1 device with 1 internal sensor, 1 battery, 1 manual

GMH 3181-13 picture
GMH 3181-13 Digital fine manometer for over / under pressure or pressure difference

Features:

Measuring range: -100 ... +2000 mbar or ( -2500 ... 0.0 mbar *)
* measuring range possible by changing the pressure connection ports

Overload: max. 4 bar rel.
Accuracy (typ. values): ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Datalogger: 99 (manually), 10000 (cycle), adjustable cycle time
Pressure units: bar, kPa, MPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tara, Scale, Offset Mains Adaptor Socket, Serial Interface
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor

Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

GMH 3161-002 picture
GMH 3161-002 Fine manometer for over/under pressure and pressure difference

Features:

Measuring range: -5000 ... +500.0 Pa (-5.000 ... +5.000 mbar)
Overload: max. 250 hPa (mbar)
Accuracy (typ. values):
- ± 0,3 % (hysteresis and linearity),
- ± 0,4 % (temperature influence from 0-50 °C)

Functions: Tare function, Hold function, Min./Max. value memory, Serial interface, Power-Off-function
Scope of supply: 1 device, 1 battery, 1 manual

GMH 3181-07B picture
GMH 3181-07B Fine Manometer ( ± 315 mmHg ... ± 420,0 mbar rel. *)

Features:

Measuring range:
-10 ... +420,0 mbar or ( ± 420,0 mbar *)
-7,5 ... +315,0 mmHg ( ± 315,0 mmHg *)
* possible by changing pressure connection ports

Overload: max. 1 bar rel.
Accuracy (typ. values):
-  ± 0,1% Full Scale (hysteresis and linearity)
-  ± 0,4% Full Scale (temperature influence from 0-50 °C)

Additional pressure units: bar, kPa, MPa, PSI, mH2O
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset d.c. connector, serial interface. 2 metal connection pins, Ø 4 mm, piezo-resistive sensor.
Scope of supply: 1 device with 1 internal sensor, 1 battery, 1 manual

BrochurePlaceholder Picture Instruction manualPlaceholder Picture
GDH 200-07 picture
GDH 200-07 Digital manometer for over/under pressure or pressure difference

Measuring range: 0.00...19.99 or 0.0...199.9 mbar rel. ( ±199.9 mbar)
Resolution: automatic change 0.01mbar /0.1mbar
Features: automatic zero point adjustment, manual slope adjustment, tare function, auto-off

GDH 200-13 picture
GDH 200-13 Digital manometer for over/under pressure or pressure difference

Measuring range: 0.0...199.9 or 0...1999 mbar rel. ( ± 1999 mbar)
Resolution: automatic change 0.1mbar / 1mbar
Features: automatic zero point adjustment, manual slope adjustment, tare function, auto-off

Brochure Instruction manual Product comparisonPlaceholder PicturePlaceholder PicturePlaceholder Picture
GDH 200-14 picture
GDH 200-14 Vakuum- / Barometer and Manometer for absolute pressure

Features:

Measuring range: 0 ... 11000 mbar (hPa) abs. -1 ... 10.000 bar rel.
Overload: max. 13 bar abs.
Accuracy: ± 3 mbar or ± 0.10 % of m.v., whichever is higher (at nominal temperature 25°C)
Selectable measuring units: mbar, mmHg, bar, PSI
Additional features: Sea level-adjustment, min./max. value memory, auto-Off, BAT, zero point-adjustment, slope-adjustment
Scope of supply: 1 device with internal sensor, 1 battery, 1 manual

Measuring range: 0 ... 11000 mbar (hPa) abs. -1 ... 10.000 bar rel.
Overload: max. 13 bar abs.
Accuracy: ± 3 mbar or ± 0.10 % of m.v., whichever is higher (at nominal temperature 25°C)
Selectable measuring units: mbar, mmHg, bar, PSI
Additional features: Sea level-adjustment, min./max. value memory, auto-Off, BAT, zero point-adjustment, slope-adjustment
Scope of supply: 1 device with internal sensor, 1 battery, 1 manual

GPB 3300 picture
GPB 3300 Digital barometer

Features:

  • Resolution 0.1 mbar
  • Sea level-adjustment
  • Manual slope and offset adjustment

Measuring range: 300.0 ... 1100.0 mbar (hPa) abs.
Overload: max. 4000 mbar abs.
Accuracy: ± 2.0 mbar (at 0-50°C)
Selectable measuring units: mbar, mmHg
Additional features: Sea level correction, Min-/max- value memory, Auto-Off, BAT, Zero-function, digital offset and scale adjustment
Scope of supply: 1 device incl. sensor, 1 battery, 1 operating manual

Brochure Instruction manualPlaceholder PicturePlaceholder Picture
GTD 1100 picture
GTD 1100 Digital barometer, altimeter, thermometer

Measuring range (temperature)-10.0...+50.0 °C resp. 14.0... 22.0 °F
Measuring range (pressure): 300.0...1100.0 mbar resp. 225.0...825.0 mmHg
Measuring range (high): -500...+9999 m resp. -1640...19999 ft
Features: sea level adjustment, offset and slope adjustment, tare function, auto-off, sum function, tendency meter, etc.

GMH 3161-01 picture
GMH 3161-01 Digital Fine Manometer incl. Sensor ( ± 2500 Pa rel. *)

Features:

  • Relative pressure sensor for over, under or differential pressure
  • Suitable for air or non-corrosive or non-ionising gases

Measuring range: -100 ... +2500 Pa or ( ± 2500 Pa *)
*measuring range possible by changing pressure connection ports
Overload: max. 100 mbar rel.
Accuracy: ± 0.3% Full Scale (Hysteresis and Linearity)
± 0.4% Full Scale (Temperature Influence 0-50°C)

Pressure units: bar, kPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface. 2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor.
Scope of supply: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

Brochure Instruction manual Product comparisonPlaceholder PicturePlaceholder PicturePlaceholder Picture
GMH 3161-07 picture
GMH 3161-07 Digital Fine Manometer incl. Sensor ( ± 350,0 mbar rel. *)

Features:

Measuring range: -10,0 ... +350,0 mbar or ( ± 350,0 mbar *)
*measuring range possible by changing pressure connection ports

Overload: max. 1 bar rel.
Accuracy (typ. values): ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)
Pressure units: mbar, bar, kPa, MPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface. 2 Pressure Connection. Ports Ø4mm, Piezoresistive Sensor.
Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

GMH 3161-07B picture
GMH 3161-07B Digital Fine Manometer incl. Sensor ( ± 420, 0 mbar rel. *)

Features:

  • Relative pressure sensor for over, under or differential pressure
  • Suitable for air or non-corrosive or non-ionising gases
  • Suitable for checking blood pressure devices

Measuring range: -10,0 ... +420,0 mbar or ( ± 420,0 mbar *) /
-7,5 ... + 315,0 mmHg ( ± 315 mmHg *)
*measuring range possible by changing pressure connection ports

Overload: max. 1 bar rel.
Accuracy: ± 0,1% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Pressure units: mbar, bar, kPa, MPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface.

2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor
Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

Brochure Instruction manual Product comparisonPlaceholder PicturePlaceholder PicturePlaceholder Picture
GMH 3161-07H picture
GMH 3161-07H Digital Fine Manometer incl. Sensor ( ± 70,00 mbar rel. *)

Features:

Measuring range: -1,00 ... +70,00 mbar or ( ± 70,00 mbar *)
*measuring range possible by changing pressure connection ports

Overload: max. 1 bar rel.
Accuracy (typ. values): ± 0,1% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Pressure units: mbar, bar, kPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset Mains Adaptor Socket, Serial Interface.
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor

Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

GMH 3161-12 picture
GMH 3161-12 Digital Vacuum and Barometer incl. Sensor ( 0 ... 1300 mbar abs. )

Features:

  • Absolute pressure sensor for vacuum and barometric pressure
  • Suitable for air or non-corrosive or non-ionising gases

Measuring range: 0 ... 1300 mbar
Overload:
max. 4 bar abs.
Accuracy: ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Pressure units: mbar, bar, kPa, MPa, mmHg

Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor

Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

Brochure Instruction manual Product comparisonPlaceholder PicturePlaceholder PicturePlaceholder Picture
GMH 3161-13 picture
GMH 3161-13 Digital Manometer incl. Sensor ( ± 2000 mbar rel. *)

Features:

Measuring range: -100 ... +2000 mbar or ( ± 2000 mbar *)
*measuring range possible by changing pressure connection ports

Overload: max. 4 bar rel.
Accuracy (typ. values): ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)
Pressure units: mbar, bar, kPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor
Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

GMH 3181-01 picture
GMH 3181-01 Digital fine manometer for over / under pressure or pressure difference

Features:

  • Integrated relative pressure sensor
  • Suitable for air or non-corrosive or non-ionising gases

Measuring range: -100 ... +2500 Pa or ( -2500 ... +2500 Pa *)
Overload: max. 100 mbar rel.
Accuracy: ± 0,3% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Datalogger: 99 (manually), 10000 (cycle), adjustable cycle time
Pressure units: bar, kPa, PSI, mmHg
Additional features:  Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset Mains Adaptor Socket, Serial Interface
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor

Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

Brochure Instruction manual Product comparisonPlaceholder PicturePlaceholder PicturePlaceholder Picture
GMH 3181-07 picture
GMH 3181-07 Digital fine manometer for over / under pressure or pressure difference

Features:

Measuring range: -10 ... +350 mbar or ( -350 ... 0.0 mbar *)
*measuring range possible by changing pressure connection ports
Overload: max. 1 bar rel.
Accuracy (typ. values): ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Datalogger: 99 (manually), 10000 (cycle), adjustable cycle time
Pressure units: bar, kPa, MPa, PSI, mmHg
Additional features: Auto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset Mains Adaptor Socket, Serial Interface
2 Pressure Connection Ports Ø4mm, Piezoresistive Sensor

Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery

GMH 3181-12 picture
GMH 3181-12 Digital vacuum-/ barometer for absolute pressure

Features:

  • Integrated absolute pressure sensor
  • Suitable for air or non-corrosive or non-ionising gases

Measuring range: 0 ... +1300 mbar abs.
Overload: max. 4 bar abs.
Accuracy: ± 0,2% Full Scale (Hysteresis and Linearity)
± 0,4% Full Scale (Temperature Influence 0-50°C)

Datalogger: 99 (manually), 10000 (cycle), adjustable cycle time
Pressure units: mbar, bar, kPa, MPa, PSI, mmHg
Additional features:  SeaLevel-correctionAuto-Off, BAT, Min-/Max-Wert, Hold, Tare, Scale, Offset, Mains Adaptor Socket, Serial Interface, 1 Pressure Connection Ports Ø4mm, Piezoresistive Sensor
Shipment: 1 Pressure Device with Internal Sensor, 1 Manual, 1 Battery
